SERIOUSLY SAFE LIGHTS™
Description:
Specs
Compliance
Download
Electrical Parameters
Power (W)
21W, 40W, 50W, 60W
VOLTAGE(V)
21/40/60W: 120-277V AC
50W: 347-480V AC
Frequency
50/60Hz
Power Factor
>90%
THD
<20%
L70
130,000 Hours@149°F
Dimming
0-10V
Surge Protection
6KV Line-to ground
Warranty
LEDs: 10 Years Driver: 7 Years
Optical Parameters
Lumen Output
21W: 4,220Lm
40W: 6,499Lm
50W: 7,179Lm
60W: 8,514Lm
Lumen Efficacy
162Lm/W
Available Beam Angle
T2/T3/T5
Correlated Color Temperature (CCT)
3000K/4000K/5000K
Color Rendering Index (CRI)
Ra>70
Mechanical Parameters
Finish
Thermoset Powdercoat
Hardware
Stainless steel 316
Lens Material
Tempered Glass or Polycarbonate
Mounting Options
Pendant, Yoke, Ceiling, Stanchion, Wall
Product Weight
21W: 10.5lbs/4.8kg
40W: 10.8lbs/4.9kg
50/60W: 11.7lbs/5.3kg
Cable Entry
(1) 3/4″ NPT w/3’ 18/6 Leads (L/N/G,Dim+/Dim-/12V)
Product Dimensions(L×W×H)
9.7×8.3×5.6in (245×210×142 mm)
Environmental Parameters
Ambient Operating Temperature
21/40/50W: -40°C~+65°C(-40°F~+149°F)
60W: 64°C(147°F)
T-Code Rating
21W: CID2–T4A, CIID1–T6
40W: CID2–T4, CIID1–T6
50W: CID2–T4A, CIID1–T6
60W: CID2–T4, CIID1–T5
